Ber-Chim is a two-component chemical anchoring system based on polyester resin for anchoring applications in concrete, brick, natural stone and wood.
Use our convenient calculator to determine the required product consumption.
Applications:
- Anchoring in dry and damp substrates.
- Fixing reinforcement bars, bolts, screws and threaded rods.
- Suitable for medium to heavy-duty loads.
- Anchoring in concrete, brick, wood and other solid construction materials.
Properties:
- Styrene-free, making it ideal for indoor use and enclosed spaces.
- Fast curing and short working time for time-sensitive applications.
- Highly versatile for masonry, hollow blocks and aerated concrete.
- Can be applied at temperatures down to -10 °C.
- Highly durable and resistant to chemicals.
- Fire resistance up to 240 minutes (SIGGMA).
- Density: 1.61 kg/m².
- VOC A+ Rating.
Standards
- 12/0024 - ETA Option 1
- 14/0057 - ETA TR023
- CE Certified 1404-CPR2583
- EUROFINS LEED
- R240 Fire Test Report SIGGMA
- VOC emission class A+
Varianten
Varianten worden gefilterd…
BOUWCCHANK0365
Packaging: Cartridge
Contents: 300ml
The product has been added to your quote request
| Article number | Packaging | Contents | Add to quote | |
|---|---|---|---|---|
| BOUWCCHANK0365 | Cartridge | 300ml | The product has been added to your quote request |
Calculator
Calculate the number of cartridges required for your project
mm
mm
ml
ml
ml
ml
ml
mm
These calculations are based on:
Standard extrusion waste per cartridge and the annular volume between the thread pitch diameter and the average drill hole diameter. Filling the holes to the indicated level ensures the published performance is achieved. Concrete hole diameters are based on the technical data sheets. This information is provided for guidance only.
